GV8 type gauge valve is a block and bleed needle pattern gauge valve with specially designed integral bleed of M8. Ideal for use on applications requiring bleeding or venting of media. Self centering needle non-rotating, on the valve seat. The conical metal tip (stem type CT) press fitted ensures perfect alignment for positive bubble tight shut-off. Standard end connections are male inlet and female outlet or female inlet and female outlet from 1/4” to 3/4”.
Applications
Installation of instrument and gauge. Instrument isolation. Venting of Instrument Liquid and vapor service
Technical Specificatons
Design Pressure
6000 PSI
Max temp.
240 °C
Material
Stainless Steel
Stem
(Type CT) Conical tip press fitted hard chrome plated
